|Place of Origin:||China|
|Minimum Order Quantity:||1piece|
|Packaging Details:||Container transpor, the general situation of the tower for metal reinforcement bind.|
|Payment Terms:||L/C, T/T, Western Union|
|Material:||Angle SteelQ345/Q235||Maximum Design Wind Speed:||36m/s|
|Quantity Of Platform:||Quantity Of Platform||Lifetime:||More Than 30 Years|
|Application:||Mobile Communication Tower||Surface Treatment:||Hot Dip Galvanized|
4 Legged Telecommunication Steel Tower,
80m Telecommunication Steel Tower,
4 Legged angular tower
4-legged Self-supporting Steel Tower for mounting telecom antennas and radio microwaves
Hot dip galvanized steel antenna tower with 1-5 workplat forms for mounting multiple GSM or 5G stations
Free standing steel radio tower, TV tower and telecom signal transmission tower
Angular Steel Lattice Telecommunication Tower with 4 legs, free standing fixed by steel frame concrete foundations
Steel Radio Tower, GSM and 4G/5G cellphone station tower, antenna tower, TV tower, radar tower, lighting tower and watching tower
High quality structural low carbon steel tower used for mounting radio and TV antennas
Communication tower is a kind of signal transmission tower, also called signal transmission tower or
signal tower. Its main function is to support signal transmission and support signal transmission antenna.
Purpose Mobile/Unicom/Transportation Satellite Positioning System (GPS) and other communication departments.
The communication tower is characterized by the fact that in the construction of modern communication and
radio and television signal transmission tower projects, whether users choose the ground plane or the tower
on the top of the building, the communication tower will act as a high communication antenna, increase the
service radius of communication or television transmission signal, and achieve better communication effect.
|No.||Description||Detailed Specification and Major design Parameters|
|1||Design Code||ANSI/TIA222G, European Standard and others|
|2||Design Loading||1. Antenna load area as per specified by Clients worldwide.
2. Wind speed as per requested by the clients.
3. Deflection & Twist Angle, Exposure category, Topographic category as per specified by clients.
|5||Hot-dip galvanization||ISO 1461 2009, ASTM A123|
|6||Steel Grade||1. High strength low alloy structural steel: Q420B which is equivalent with ASTM Gr60
2. High strength low alloy structural steels: Q345B which is equivalent with ASTM Gr50 or S355JR
3. Carbon Structural Steel: Q235B which is equivalent with ASTM A36 or S235JR
|7||Bolts and Nuts||Mainly ISO 898 grade 6.8 and 8.8 bolts|
|8||Foundation||50KPa, 100KPa, 150KPa soil bearing capacity mainly.|
|9||Tower Type||1. 3 Leg Self supported Angular Towers
2. 3 Leg Self supported Tubular Towers
3. 4 Leg Self supported Angular Towers
4. 4 Leg Self supported Tubular Towers
5. Guyed Mast
6. Monopole Tower
7. Camouflaged Tower: Palm Tree, Pine Tree, Coconut and others tree
8. RDS Tower: Rapid Deploy Site/Tower
9. Rooftop Towers
10. Smart Poles
|10||Warranty||1. Tower structures: 10 years
2. Camouflaged towers
a. Barks: 10 years
b. Branches and leaves: 3 years
|11||Return Period||50 Years|
|12||Accessories||1. Paint kits (ICAO standards): Water Based Acrylic Anticorrosive Paint which include Primer, International Orange/Red and Ivory White
2. Aviation Light: 48V/220V Double Light and Single Light & Solar Light
3. Lightning System: Lightning rod with 70mm2 G/Y copper cable down conductor or 25x3mm copper flat tape with clamps, and copper coated steel busbars or as per specified by clients.
4. Earthing System: Earthing Rod with copper clad steel strand cable and lugs etc. or as per specified by Clients.
5. ACDB as per specified by clients
6. Fencing: Palisade fence and wire mesh fence with razor wires and gate.
7. Fall arrest system: GB and CE certificate fall arrest system.
8. Optical Fiber Cable: as per specified by client
9. Generator: as per specified by client
10. Canopy and Generator Cage: as per specified by clients
Purpose of TV tower: TV tower is mainly used for transmission and transmission of microwave, * short-wave
and wireless network signals. It is a building used for broadcasting and television transmission. In order
to make the broadcasting range larger, the television transmission antenna should be higher. In this way,
the TV tower will be higher and higher, and finally become a modern high building. We should spread TV
to every household
Hebei Chang Tong Steel Structure Co., Ltd.located in the hometown of China Tower, is a
modern big-scale professional company fabricating triangular communicationtower,
four-corner communication tower, cable tower, single-tube tower,camouflage
communication tower and transmission linetower.integrating design,fabrication
and marketing,annual production capacity reaches more than 30,000 tons.
Company always adhere to the business strategy of "surviveby quality, develop by credit,
increase efficiency by science andtechnology", continuously carry out technical transformation,
complete production equipment, reliable production process,adopt advanced CNC angle steel
production line, CNC sheetproduction line and various supporting equipment. The
equipment has a first-class iron tower stakeout center, all of which implement microcomputer
lofting, which guarantees the processing quality and provides a strong guarantee for production,
which can fully meet the design and productionrequirements of various types of towers and substation
Our steel tower products have won good reputation from our customers,including China tower,
China mobile,China unicom,China telecom,State grid and so on.In addition,our products also
were exported to many countries and areas,including South American,Africa,Southeast Asia and
