Hebei Changtong Steel Structure Co., Ltd.
20 years of communication tower design and production experience
Provide comprehensive professional consulting services
Has served countless communication carriers
 |
| Place of Origin: | China |
| Brand Name: | ChangTong |
| Certification: | ISO9001:2008 |
| Model Number: | JGT190409-2 |
| Minimum Order Quantity: | 1piece |
|---|---|
| Price: | USD1000-15000 |
| Packaging Details: | Container transpor, the general situation of the tower for metal reinforcement bind. |
| Delivery Time: | 30-45days |
| Payment Terms: | L/C, T/T, Western Union |
| Supply Ability: | 20000Tons/year |
| Product Name: | Mobile Cell Tower | Material: | SteelQ345/Q235/ASTM A36 A572 Gr50 |
|---|---|---|---|
| Appearance Treatment: | Hot-dip Galvanized/powder Coated/painting | Height Of Tower: | 15m-80m/Customized |
| Connection Structure: | Flange Connection/bolts Connection | Maximum Design Wind Speed: | 30m/s |
| Quantity Of Platform: | 2/3/Customized | Antenna Type: | GSM, RRU,CDMA, MW Etc. |
| Lifetime: | More Than 30 Years | ||
| High Light: | Telecom Mobile Cell Tower,100M Mobile Cell Tower,100M 10kV Telecom Cell Tower |
||
Environmental Telecom Mobile Cell Monopole Signal Tube Tower
Chang Tong mainly design all kinds of towers and posts for:
a. Telecoms
b. Power transmission
c. TV and Radio Broadcast
d. Roads and City Development
e. Wind tower and energy solution
f. Steel workshop and other steel structures
Our complete selection of towers includes:
a. Self-supporting
b. Monopoles
c. Guyed towers
d. Custom-designed radar towers
e. Broadcast towers
f. Power transmission
Chang Tong also designs and manufactures tower related products including:
a. Fall protection
b. Antenna brackets
c. Other accessories if needed by clients
This photo refers to our MEGATRO 60m lattice SCADA-Telecommunication system Tower, which we exported to South-East Asian countries in year 2015, some of design data as follow:
Technical Specification:
1) 3-Legged telecommunication 60-meter self supporting steel structure aesthetically.
2) These steel towers structure shall be hot dipped galvanized to BS 729 and must resist all surface corrosion. The manufacturer and workmanship of the structures shall be to BS 449 or equivalent.
Overview
The Steel Antenna Microwave Communication Monopole is made by the high-quality hot rolled steel plate which was bent into Trapezoid according to the poles's dimension,then welding ,grinding,hot dip galvanized and packing for delivery as following shows:
Telecommunication Tower- Goods description and major parameters
| Height | From 10M-100M or according to client’s requirement | |||||
| Suit for | Electric Power Transmission and Distribution | |||||
| Shape | Polygonal or Conical | |||||
| Material | Normally Q235B/A36,Yeild Strength≥235MPa | |||||
| Q345B/A572,Yeild Strength≥345MPa | ||||||
| As well as Hot Rolled coil from ASTM572, GR65,GR50,SS400 | ||||||
| Power Capacity | 10kV to 500kV | |||||
| Tolerance of the dimension | According to client’s requirement | |||||
| Surface treatment | Hot-dip-galvanized following ASTM123, or any other standard by client’s requirement | |||||
| Joint of Poles | Slip joint, flanged connected | |||||
| Standard | ISO9001:2008 | |||||
| Length of per section | Within 13M once forming | |||||
| Welding Standard | AWS(American Welding Society)D 1.1 | |||||
| Production Process | Raw material test-cutting-bending-welding-dimension verify-flange welding-hole drilling-sample assemble-surface clean-galvanization or power coating /painting-recalibration-packages | |||||
| Packages | Packing with plastic paper or according to client’s requirement | |||||
| Life Period | More than 25 years, it is according to installing environment | |||||
